PA66 Nylon filtering mesh 110T Food Grade FDA 15 Micron
Nylon PA66 Filter Mesh is a versatile material due to its great strength, flexibility, long life and resistance to abrasion. Nylon has excellent resistance to most common solvents and will operate continuously at temperatures up to 160°C in the chemical pH range 7-14.
1.Density Uniform
2.SGS;FDA certificate
3.High durability and best tensility
PA66 Nylon Mesh Description:
Material: 100% nylon PA66
Weaving: Plain weave
Mesh Count: 4T~150T mesh/cm(10mesh~380 mesh/inch)
Max. width: 365cm (143inch)
Color: white
Monofilament
We can provide products in special specifications according to your demand.
Application of PA66 Filter Mesh:
Medical filtration, blood filtration, liquid screening
Solid-liquid separation
Particle filtration
Cell and algae screening
Solvent pre-filtration
Paint filtration
Glue, paste filtration
Oil filtration
Particle analysis
Food filtration screening
Background filter for automatic particle imaging systems
Features & advantages:
1. High tension and smooth surface
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear
7. Imported weaving machines from Switzerland and Italy
| 100% Nylon Mesh |
| Type | Mesh/CM | Mesh/inch | Wire Dia.
(um) | Mesh Opening(um) | Open Area
(%) | Thickness
(um) |
| JPP4/550 | 4 | 10 | 550 | 1950 | 61 | 1096 |
| JPP5/500 | 5 | 13 | 500 | 1500 | 56 | 998 |
| JPP6/400 | 6 | 15 | 400 | 1267 | 58 | 796 |
| JPP7/350 | 7 | 18 | 350 | 1079 | 57 | 691 |
| JPP8/350 | 8 | 20 | 350 | 900 | 52 | 697 |
| JPP9/250 | 9 | 24 | 250 | 861 | 60 | 492 |
| JPP10/250 | 10 | 25 | 250 | 750 | 56 | 494 |
| JPP12/300 | 12 | 30 | 300 | 533 | 41 | 590 |
| JPP14/200 | 14 | 35 | 200 | 514 | 52 | 391 |
| JPP16/200 | 16 | 40 | 200 | 425 | 46 | 393 |
| JPP18/200 | 18 | 45 | 200 | 356 | 41 | 395 |
| JPP20/200 | 20 | 50 | 200 | 300 | 36 | 396 |
| JPP24/150 | 24 | 60 | 150 | 267 | 41 | 292 |
| JPP28/150 | 28 | 70 | 150 | 207 | 34 | 295 |
| JPP30/120 | 30 | 76 | 120 | 213 | 41 | 230 |
| JPP32/100 | 32 | 80 | 100 | 213 | 46 | 186 |
| JPP36/100 | 36 | 90 | 100 | 178 | 41 | 189 |
| JPP40/100 | 40 | 100 | 100 | 150 | 36 | 192 |
| JPP44/100 | 44 | 110 | 100 | 127 | 31 | 195 |
| JPP48/80 | 48 | 120 | 80 | 128 | 38 | 150 |
| JPP56/60 | 56 | 142 | 60 | 119 | 44 | 96 |
| JPP59/60 | 59 | 150 | 60 | 109 | 42 | 110 |
| JPP64/60 | 64 | 163 | 60 | 96 | 38 | 116 |
| JPP72/50 | 72 | 183 | 50 | 89 | 41 | 90 |
| JPP80/50 | 80 | 203 | 50 | 75 | 36 | 93 |
| JPP88/43 | 88 | 224 | 43 | 71 | 39 | 70 |
| JPP96/43 | 96 | 244 | 43 | 61 | 34 | 74 |
| JPP100/43 | 100 | 254 | 43 | 57 | 32 | 75 |
| JPP104/43 | 104 | 264 | 43 | 53 | 31 | 76 |
| JPP110/43 | 110 | 280 | 43 | 48 | 28 | 78 |
| JPP120/43 | 120 | 305 | 43 | 40 | 23 | 80 |
| JPP130/43 | 130 | 330 | 43 | 34 | 19 | 83 |
| JPP140/38 | 140 | 355 | 38 | 33 | 22 | 73 |
